SKU
L3-1K
L3-1K Subwoofer Amplifier
Leon’s L3-1K Class A/B subwoofer amplifier delivers the power, refinement and flexibility that our Aaros subwoofers deserve. And with 1,000W of clean power, adjustable crossover, variable phase, and tunable EQ, the L3-1K subwoofer amplifier provides fully controllable sound to enhance any listening experience.
Starting at
$2,100.00
- 1,000W, dual-channel, Class A/B subwoofer amplifier provides clean, controlled output
- Low frequency parametric EQ allows you to tailor the sound
- Patented tracking down-converter power supply for high efficiency
- Manual, auto or triggered on/off for easy integration
- Switchable subsonic and bass boost filters
- High pass output sends signal back into integrated systems
| Height | 3.5" (2U) |
|---|---|
| Width | 17” |
| Depth | 13" |
| Weight | 30 lbs. |
| Power Output | 1,000W into 4Ω; 500W into 8Ω |
| Power Requirements | 120/230 VAC |
| Crossover | 30–200Hz (with bypass) |
| Standby Power | 120V 24W; 230V 18.4W |
| Bass Boost | -3 dB @ 25 Hz, Q=1.4 |
| High Pass | -3 dB @ 80 Hz, 12 dB/octave |
| Low Pass | 30-200 Hz |
| Analog Inputs | RCA-style jacks: L/R, LFE; 3.5mm 12V Trigger |
| Outputs | 2 channels |
| Signal Sensing | Yes |
| Control | 12 Volt trigger |
| Line Voltage | 100-120VAC/200‐240VAC Switchable |
